Pnwtree

Interesting how increased stretch would change peak power and how long power stays on. Yea since this dyno ive now been testing on what is best fuel stretch. Yea ive noticed a slight diff in 23 to 24 and at 3000 i havent tested too much. Also another thing to note, is the guy stopped right at 3100, soon as it got there the power dropped off quite a bit and didnt really want to go too much further.

Couldnt figure out which thread to post new v2 info o found out on the dyno so figured id use my thread and tag the v2 guru. So did 3 pulls, wish i had done more but oh well. 1st pull one of by basic race tunes with 19* at 2000 23* 2500 26* 3000. The chart shows low mph but at 74 mph its actually 95, max rpm was 3100 starting was roughly 2000 rpm. This is run #1 Run #2, adjusted timing to 14* 1500 20* 2000 24* 2500 27* 3000. Peak horsepower not much change but the advantage on my truck was power on little faster, the charr showed a much smoother power curve, and kept a extra 30 horse before it wanted to drop off. More timing up high proved to hold the power a bit longer. Final tune had the same exact timing (20* 24* 27) same eveerything else except fuel stretch. I changed it from 1900 to 1700 and the resultes o was pretty shocked about. Starting power was much higher, max hp was i ncreased another 30, torque stayed on longer and was very impressive. Hope this helps someone out, its not much but i found it interesting and wish i had did more pulls to try tuning more. One thing id like to ask about all this that would help me figure out the best power tune is how does the fuel stretch duratio work? Is it the extra 30% canbus from the wire tap? If so whats the advantage past 1200 on the stretch?

I see, well thats good to know. Havent had that code(yet). Lol

I see, thanks for all the great info really enjoy learning the v2 tuning. Okay is it possible that failing vp can retard or advance or not really? Id heard something about it but wasnt sure. I see, mine where just smokey, always grey ish smoke hardly ever bacl except for when i had used a smarty s03. Yea lol thats why i originaly bought em, then power adiction got worse. Just checked it out very helpful!

Sweet thats good to know, i figured woukdnt be a issue with studs but cant be too safe when i get close to 70lbs of boost wot. Havent played with the load timing reduct but ill give that a go as well. Is the bucking from too much timing? Ive had that happen at mid throttle higher rpm. I recently started using the low load timing adv and that made a huge difference for mine. Cruising a 4-6% grade id get to 1000+ egt(not towing) now when i use that it sits at like 22-23 egts are 700-850 doing 70-75. Was amazed how much difference that made. Yea not a problem, mine actually does amazingly well since i swaped 7x.011 daps for westons 6x.013. One a side not i saw in your sig you have 7x.012 daps, do they run well? My 7x.011 where crap and egts where higher than my 6x.013s and not crap for power. Wondering if its a crappy set was all.

So ive been doing a lot of playing around with the v2, and one tricky thing that i would like to get other opinions and ideas of what they run for more power is the timing adjustment per rpm. Im curious what others have found to be the best for power but within safe range of course. Ive tried a few different mixes but i feel other opinions and what others have tried will help. Also is it possible for the vp44 timing electronic to advance or retard timing? Thanks for the input

Lol wish i was smart enough to ask the experts before i made my purchases 2 twin kits and 3 sets of injectors later.... lesson learned!

Well case closed finally, turns out the last twin kit interstage pipe probably was the culprit in the boost cut off. As for 56lbs of boost, well what's the odds of 3 boost preassure guage all having max reading of 56.... granted one is off map sensor, but one is glowshift 0-60 guage, one is the quad, and last is unknown max snow performance water meth. So yea anyways stuck a air chuck on them and learned the problem. Explains why been blowing boots now. Thanks for help, shity that it was so simple lol

Lol well I'm back at it again, replaced the intercooler with mishimoto, It ended up not being the fix for my issue though I know my old Ic was leaking so wasn't a complete loss. I installed my dp guage, and ratio in the low end is around 1.1 and then as soon as it high 56 boost my dp still goes up, hit 70psi on so guage then blew a boot on hot side of intercooler. That being said I must still have a leake? But I don't know where. Only thing I know that might and didn't show on leak test is intake plenum gasket. I did use a AutoZone one when I got the billet plenum. That or it's internal? Any thoughts..... at a loss and losing my mind.

Okay I'm probably going to try a different set of injectors and see how they do, acorinding to diesel injector shop, the spray pattern is wider, and I guess that can cause problems. Pump shows no sighns of going out and it is a reman from previous owner. Any recommendations for injectors? Power goal is 600+ hp, don't tow much so looking for performance.

Yea I agree, that's why I wish I wasn't being cheap and did more research before buying them. The 120s are 7x.09 I believe. Guess what I'm pretty much trying to find out is what would be a good fit, I understand big injectors especially 6x.013 will have a haze but these 7x.011 haze a lot, even more than the 6x.013 according to some of people's pics. Does it while cruising. It's clear these seem to waste a lot of fuel. Pretty much just looking for advice on what would work and what's good, I like the idea of 6 hole only cause the faster spool up. Yea I was hoping it could clean up the idle and cruising haze but it didn't really help, even with new v2 tuning.

Well think I finally figured it out, knock on wood. Ended up pulling everything off the front to do a solid check on intercooler and sure as **** and sure enough right behind the condenser, there's 4 spots that it was throwing steady bubbles at maybe 15 psi so thinking that gatta be the reason. Will find out in a week ordered a new intercooler.

So I've bought a set of sac 7x.011 dap nozzles 7 months ago, had them sent to local injector shop, right off the bat they said they look cheaper(they are by a bit), and the spray angle is wider. Dap claims there 225 hp injectors. They seem to not be much better than the 120s from ii I had on before, maybe got a little more power, a nasty haze at idle and white cruising. On top of that comes out more white ish black than just black on take off. That being said I'm interested in the weston 6x.013s and wanted to see how good they are and if they are as dirty. Let me know what ya think. Thanks

Yea I was possibly thinking a cracked intercooler, I'm going to do drive preassure test first since it's cheap and eliminate possibility of under fueling then look into that. Yea tried that on last twin kit, didn't change the one I have now is brand new.

Yea I just ordered the stuff to do a drive preassure guage, so I'll let you know in a few days what thats looking like. I'm kinda convinced it's the dap nozzles cause the power difference between the ii 120s I had in it before aren't much and have more white smoke from 225s compared to the 120s which did more black. 1 is map read out, 2 are manual map read out says 55 manuals say 56. I'll do interstage when I get another guauge, my new setup is a s475 96 1.32 under a 62 68 12 sxe. I also know the spray angle on the 225s are wider than the other people's injectors. The other two guages I have read from intake horn(water meth) and guage pillar reads from intake.

Nope nothing like that, and made sure limiters are off on the quad.

Sorry I dropped off, but if anyone is still chiming in I have a update. I went ahead and switched out my old twin kit thinking it must be why is was cutting out and it did. But for some reason with the new kit I cannot get over 56lbs of boost(last kit just dropped at that boost preassure). I can hold it at that but will not go any higher. I did a boost leak test and found a few small leaks, fixed them and problem is still there. Totally stumped on why it doesn't want to go past that. I'm running dap 7x.012 sac nozzles (claim 225hp). I'm guessing it actually is electronic or maybe something more internal? Idk

Okay so big update, I found that when I this happens and my boost preassure plummets, I'm still blowing smoke out the tail pipe so I'm fueling, I don't think I'm fueling as much because egts never got out of control when boost drop but was still dumping fuel out tail pipe. Also makes a winding noise with a sort of sucking sound when happens.

Yea that was the plan, but manual pcm from donor truck wouldn't run, and I've had a few people tell me it should matter. Power is also great up until this point. Happens around 2500 in 5th gear, 3k in 4th, also depends if I open or close my Watergate. Open since boost won't build as high I can hold it to higher rpm, but get higher egt(about 1350) closed 8 get maybe 1200 egts but can happen bellow 2500 rpm. What do you mean interstate boost? Drive preassure I'm not sure, need to get a guage for it, what do you mean interstage boost?

Yea I can do that later today, I'll put the v2 back on and give it a try holding to the floor and post my data logs with v2 holding to the floor after dead pedal.

Power completely drops, fueling stops, let off and full power again. Yea the log was when I flashed to v2, then flashed back to adr3000 to find out if it was the v2 causing it. Right now adr3000, but does it on both. Vehicle profile is 1998.5-2000 for adr3000

Yea technically off the log in making 56-57 on my manual guage. Do they make a sensor that exceeds that then? I know a few people that have no problem seeing 60+psi with no dead pedal. Also don't get any codes other than soft codes for the old auto tranny I had in it.

Even with the boost fooler of the quad? I though boost cooler doesn't allow ecm to see past 20 so would that matter? If not what map sensor would be better?

I can do that later on when I'm home for work, I had done that and had it sent to quad, they didn't see anything really unusual other than boost preassure did a full drop to 0 psi got half second, then back to 7. Which is weird cause if i go to 53lbs of boost and let off before dead pedal it always goes to 6-7 then sliwly drops not instant. I'll post the log later on today. I did notice that to be weird though. This is the breakdown quad sent me, I'll get the one I got later. Let me know if this helps

Hi I'm new to the site but have learned so much and hoping you guys can help me out. I've been getting a dead pedal at 53-55lbs of boost, things I've done aside from power mods are auto to nv5600 and 2001 fuel filter with twist off cap. Power mods are on my profile. I've replaced apps, map sensor, made sure the quadzilla is good, have good fuel preassure, and great power till that specific boost. Any ideas would help. Thanks.
