I made it with ptfe stainless steel braided lines . easy to route and durable . little bit expensive!! durable. its been 2-3 years summer and winter driving. no problems

On transmission case its 1/4 npt . and on heat exchanger its 3/8npt and one 1/2 npt if I remember.. I put -8an lines on my 2001 so 2x -8an to 1/4 npt ---- 1x -8an to 3/8npt --- 1x -8an to 1/2 npt .. and fittings for cooler or coolers you use

what's your line pressure?? there's a plug on helper side of the tranny. you can hook a gauge to see the pressure

the tv cable is at the bottom. the adjustment is at the back of the bracket near or at the side of fuel filter canister. it's just a plastic clip that lock in groove for adjustment. take care to not broke the clip!

check your tv cable for correct adjustment!

Yes exactly for the money difference!!! and yes exactly you need money in hand if you found a real nice one or a deal. they're not last long!! More luck to find a good one for you guys in USA than in Canada. Here in Quebec there's a lot of rusty trucks even mine start a lot. Winter Salty roads of Quebec

the whinning noise is possibly the torque converter???

do you check and smell your tranny oil? if there's some parts in it???

try reset APPS and inspect the plug,connection on the altenator

Maybe when the converter lock, the flexplate cork a little bit and touch those bolts!!!???

Had rebuild my transmission by myself and had little trouble. I ask him for some help. Told him the symptoms and he pin point me the cause.We found my error and now it works goodé He knows really much these transmission and also a really smart person!!

Maybe time to get a timbo apps!!! but mine work good until it get cold... this morning it was 0 celcius, the apps was 3-4 % after work at start up it was 3-4 % than take a stop at the store. When I restart the truck the apps was 2-3% .. Seems like when hot and after 3-4 start up the apps recalibrate or return at the good position itself!! really weird, hate that random trouble!!! When arrived at home I check for code and nothing .. All ok now its the apps problem that bugging me! Thanks guys for infos

Yes I check APPS % with the edge module, same thing for the code!! In summer the APPS was fine like 0-1% but when the cold comes and grid heater cycling, it seems it bugs something . Apps goes 4-5% sometimes 6-7-8% . really strange. Hate technologie with the electronic hahaha thanks @likeoldford wish to find that problem!!!!

yes maybe. its a strange problem. This morning I remove the rear speed sensor, wipe it and check for continuity. It was ok. For the grid heater relay. It has a wire unplugged! the little ones was too loose on the stud, so i take plier to pinch it.... I did the apps reset. Erase the codes. I started the truck and my apps was still at 3-4% (little less than yesterday) ... I go for a ride, my speedo works fine.... check for codes, had only p1693 and no other. I erase it. Tomorrow I'll see if it's always OK, cause the cold begins here!! Just a weird thing.. I take it to the town, the truck was hot and when I start it, even if it's hot the grid heater cycling a little ??? would like to know what tells the heater to cycling? like when cold to cycling and when hot not cycling at start up. Seems like a trouble somewhere else?? sensor?? ecm?? Thanks for help!! would like to run fine before winter!!

Nice work!! will you try it on dragstrip?

Hi guys my trouble with apps came back cause of cold weather here. Tonight I've gone for a little ride everything OK . Little trip at the market, on my way home after start the truck it has 5-7-8% of apps. I had no speedometer. Before I had the glow plug circuit 1 trouble code when the cold has arrived!!!! I'm thinking of electrical problem or if the heater relay can cause those problems?? need help about this one. its weird!!! thanks

In futur will it be possible to upoad tunes via laptop. I'm not with android Iphone or tablet ... only have laptop and dont want to buy other stuff only for the Quad .... already have the edge jwa

thanks guys!!!

hi guys, good article!! I want to know for custom tuning, can it be done on laptop or it only works on android or iphone... thanks!! I have an old cellular and dont want the new phones!

I tried with my multimeter but its not a good quality. I need to buy a good one!!

Hi guys some update!!!! it was hot here for about 2-3 weeks,so during morning startup the wait to start light doesn't came on and my apps % was good 0 to 1% nothing more. One morning it was little colder, when I start the truck I have the wait to start . So when the truck running and air intake heat cycling the Apps goes from 3-4% to 0%..... After cycle it stays at 3-4% during driving. after some driving and start- stop engine the apps return to 0-1%. I don't understand what's the trouble. like a trouble with air intake heater and ECM????? the grounds are clean!

Thanks guys!!!! I think the truck is sold. No more add but I keep his number.

Yeah, I did quick and my pad was little rough.. I need more steps with fine ones. Anyway its a oil pan, it will have dirt, oil, fly, bees haha Thanks guys for appreciation! more pics when on truck, in Futur!

Other update!!! This ones for you Mike! @mopar1973man haha . I 've take little time at my job to polish the pan.

Thanks Jag1. The next should be better!!
