I am looking at the Screaming Eagle 57/65/12 T3, I mostly pull 15k lbs loads. Not looking to hot rod just pulling and fuel mileage. I have DAP 50hp injectors. Anyone here have experience with this turbo? I recently pulled a load into a head wind and I still had plenty of HP just couldnt us it because egt's got to hot had to down shift to cool off. Thinking this turbo might cool it down a little better. Thanks

For 50 HP injectors stock turbo should be fine. I'm running 150 HP injectors on my stock HX35W (54/60/12). Climbing 7,500 into Bridgeport, CA. No EGT issues at all. My biggest problem was transmission temp that was running high from head winds. Total weight was 17,500 pounds. Boost limited to 35 PSI. Again my final ratio is 3.69 running on 245/75 R16 tires. This is the huge part having proper final ratio. Might be pizza cutter but no EGT issues.

Edited May 25, 20222 yr by Mopar1973Man

That was a job. If you are lacking in the fab department you might want to get some help. Everything was short anywhere from a 1/4 to an inch.

Photos?

If I was gonna do it all over again I would get that 57 gxe.  It would spool like crazy

This is my first new turbo, do they turn blue on the exhaust side? I havent ran it loaded yet and its blue as heck.



On 5/29/2022 at 7:04 PM, Royal Squire said:

Photos?

I need to get my phone set up on here and I'll try soon.



3 hours ago, jlwelding said:

This is my first new turbo, do they turn blue on the exhaust side? I havent ran it loaded yet and its blue as heck.



I need to get my phone set up on here and I'll try soon.



Steel turns blue between 560F and 590F so bearing in mind what a EGT probe would show (anything from 240F idling to over 900F on my truck) blue is fine

Would end up maybe steel grey  which you wouldn't see anyway and once it's got some rust on it you can't see it



https://www.anvilfire.com/21st-century-blacksmithing/temper-colors/      probably not quite the same steel as the chart  but close enough to get the idea of it all



I use charts like these quite a bit when hardening pins and bushes I make

Edited May 31, 20222 yr by wil440

This is roughly the temperature vs color on steel and cast iron.

Edited May 31, 20222 yr by Mopar1973Man

the guy is saying his turbo is blue which is 400f or so lower than the lowest on your example

Hey I just seen a Ford V10 engine turn cast manifolds glowing red hot just barely getting to 55 MPH in a class A Bounder motorhome. Those manifold were blue before we even started. You could see it in normal daylight.



It would not surprise me on a turbo being that is the narrowest flow spot and will convert heat energy to motion of spinning the turbo, it should turn that cast iron blue rapidly. Just figure 1,250°F will for sure get the color going.

Edited June 1, 20222 yr by Mopar1973Man



@Mopar1973Man, you posted the heat treat color while everything is glowing. Once past 730-750, the color actually goes away and light starts being emitted (glowing). The color is also a high level mark with no way to go back downand start over .

Being a welder for 25 years I knew it was going to change colors lol. But I should have said also I was breaking it in. For the first 10 miles I really only got it up to 600 degrees that being at the head I didnt think it would transfer a constant temp that far down the pipe. But enough of that lets get to what we really like hearing. It spools good and it keeps it a lot cooler under a load, although Ive only hauled 7500 lbs load 10 miles from here on mostly flat ground I like it. When you ease into it the temp stops climbing at 900 and you can hear it working and it just maintains. I will get back to you when I get another 15000 or better on it.
One thing that did freak me out at first was I pressured up system checking for leaks after new boost boot install and the elbow on the turbo had bubbles flying everywhere. I thought maybe the hose was cracked but I trimmed it back and soaped it up and again samething bubbles everywhere. I called Mitchell at DAP and he said that was what its designed to do. He also told me I could just get a regular elbow and put on there. Well I have parts from everything laying around and asked if I could use an old elbow from a Edge EZ and he said that was fine too, so I may try it and see what happens.

Thanks for the chat on the phone hopefully it answers your questions.

Yes, I will be saving up for the Quadzilla and get back to ya. I'll check the rotation on that driveshaft. I hadnt laugh that much in a month.

Edited June 3, 20222 yr by jlwelding
