Testing terminals for trailer tow relay in the PDC. Tools needed: a Jumper wire and test light. Is there 12V at terminal #30? if no check fuse #8 in the PDC. Is there 12v at terminal #86 with the headlight switch in the on position? If no check the headlight switch. Is terminal #85 grounded? With test light prob in terminal #85 and clamp end on positive post of battery is the light illuminated? If no check ground G102. Jumper Terminals #30 and #87 with 16-12 AGW jumper wire. Does the black/orange wire at the 7-pin trailer connector have 12V? If no, then there is an open circuit (poor contact or broken wire) somewhere between the PDC and 7- pin trailer connector. All testing can be done with ignition switch in off position.

Mike, I think I found your sister.

Check pin #87 of the trailer tow relay in the PDC, that is where the wire ends. Power for it comes from 40A fuse #8 in the PDC to terminal #30 of the trailer tow relay. Power from the headlight switch goes to terminal #86 and terminal #85 is ground.

Contact Auto Computer Specialist and tell them what's going on, they have helped a lot of people here with bad ECMs over the years. Give them a call and see what they can do for you. They are listed in the vender section on this web site. Auto Computer Specialist 221 S State Rd 7, Plantation, Florida, 33317 Phone Number: (954) 513-8359

Have you connected all the ground wires that are attached to the end of this cable and grounded them to the timing case and added the ground from the case to the driver side battery? If yes, then leave it unplugged. If no, then plug it in to the right battery until you've done this step of the ground modification.

4AGW is bigger than 6AGW so no problem there. Here is how I treated the passenger (right side) battery ground. https://mopar1973man.com/cummins/articles.html/24-valve-2nd-generation_50/51_engine/electrical/pcm-ground-splice-repair-r675/?tab=comments#comment-115

I'm running the stock alternator. I use a Blue Sea Systems 5005 ANL fuse block with an ANL type fuse, but the AMI/MIDI type fuse will work also. I've done 4 trucks using this fuse setup.

I use a Blue Sea 150A fuse with the extra fuses you get in the glove box with the other spare fuses. I've never had to replace one. The reason I chose a fuse over a breaker was: the truck's stock alternator fuse is 140A and how often have you had to replace it, never? An electrical breaker is mechanical and can fail. If the alternator has an internal short, then resetting a breaker or installing a new fuse is no going to help.

You can use the power wire that went to the original lift pump to control the FASS relay, review the article for protective lift pump relay. Remove and discard the wire at the FASS relay terminal that comes from the ignition switch and attach the power wire from the ECM for the lift pump to the that relay terminal. This will give on/off control to the ECM and will turn off the lift pump any time the engine stops. This set up will also turn the pump on for five seconds when the key is first turned on and twenty seconds when the engine starter is "bumped". The coil in the relay has enough resistance so no code is set for a disconnected lift pump.

Is the fuel pump on any time the ignition key is in the on position? If in an accident what signals the fuel pump to turn off mitigating a potential fire?

You can leave the old pump on; it's not hurting anything unless it gets in the way. The old filter housing can be an extra filter, but it also serves as a water separator and a fuel heater for those cold northern winters.

Here is an article that might help to install a lift pump relay. https://mopar1973man.com/cummins/articles.html/24-valve-2nd-generation_50/51_engine/59_fuel/installing-protective-lift-pump-relay-r501/?tab=comments#comment-55

Start with the ground mod then retest for AC voltage. When testing for AC voltage the engine should be warmed up and all unnecessary lights and accessories are off.

I've done a few rear wheel bearings over the years. They're easy to check; jack up the rear axle put jack stans under the axle and chock (block) the front wheels. With a helper start the truck and shift into 1st or 2ed gear. With a mechanics stethoscope or a long screwdriver listen at the axle just behind the rear brake backing plate on both sides and compare the sound.

Now that President Biden Has removed himself from the DNC presidential process and Vice President Kamala Harris has been elevated to fill that spot this song will be used to introduce her to the convention delegates. https://www.youtube.com/watch?v=OhW6t4rEJwU

As of today, 7/21/2024, Joe Biden has announced that he is dropping out of the 2024 presidential race. With this news the White House has changed the President's official 2024 DNC introduction song. https://www.youtube.com/watch?v=PgWyvnBHyOw

The Biden White House has released its choice for the music that President Joe Biden will use when he takes the stage at the Democratic National Convention in August. https://www.youtube.com/watch?v=xMaE6toi4mk

Sounds like it maybe a tire balance problem.

Thank for the heads up. Good find!

Glad you found it. I've heard of speed sensors going bad, but this is the first time hearing that one broke off.

Which "cumminsforum" are you enquiring about?

Check the wires/connector at the speed sensor in the differential and the wires/connector between the cab and the bed to start with. If they are ok then then look at the abs controller.

Try this site. https://tiresize.com/gear-ratio-calculator/

You changed to an Edge EZ and the code still comes on as soon as the key is turned then the problem must likely is with map sensor or wires/connector. Try plugging in a map sensor without installing it and see if the code comes on without starting the engine.
