Everything posted by IBMobile
-
Timken Hub Assembly torque specs
280 ft-lb is the spec, I replaced the right one when I was at @Mopar1973Man place this spring. My torque wrench only goes to 150 ft-lb so after 150 I used my 2' breaker bar and tightened it about another 20°, peened the nut at 12 o'clock with a punch and marked it with a dab of paint. So far after over 3,000 mi of towing the nut is still in place and no problems with the hub or bearings.
-
Brake system
Replace everything when your in there or do the job again later.
-
Rusted Bolt Removal Tips Needed
Heat with oxy-acetylene torch, red hot, but don't melt the metal. Heat the flange area, that will expand the hole and brake the rust bound from the bolt.
-
2001 2500 Rapid Torque Converter Cycling
Here it is.
-
Heater core replacement coming soon. Anything else?
I've done my heater core and @JAG1work truck heater core, heater treater, AC evaporator and accumulator. I took my time doing JAG's truck because we were also tearing the roof of my 5th wheel at the same time. His truck took a day and a half with all the interruptions.
-
New Member
Welcome to the forum. This web site run on donations and subscriptions to pay for the server, software, hardware, and all other related costs.
-
differential & transfer case oil & seals
Get the vehicle ID number and go to a Dodge dealer parts or service department; see if they will print the factory build sheet for it.
-
We have Extreme Fire Conditions starting 5 pm This Evening
I just got off the phone with JAG1. He is under mandatory evacuation and is living in his camper at a church campground. Keep him in your prayers.
-
Mounting a 70 gallon Freightliner tank in the bed.. Suggestions/Ideas?
YouTube Auxiliary fuel tank for pickup truck part 1 Auxiliary fuel tank for pickup truck part 2
-
2nd gen PCM functions
You can replace the diodes at home. the diodes are sold in the store here. There may be another problem causing the diodes to go bad such as one of the batteries going bad or a bad cable/connection between batteries or ?. You need to have the charging system fully tested and do the W-T ground wire mod along with this modification shown below.
-
Squealing when turning the steering wheel
That squealing sound is most likely the pressure relief valve in the pump or a valve in the steering gear.
-
Sealing Vent Hatches on the RV Roof
Me too! @JAG1 would still be picking bugs out of his teeth.
-
Sealing Vent Hatches on the RV Roof
It took us about 10 days, not full time, but the last 3-4 days was was the hardest. JAG1 came through with his carpentry skills on patching a few holes; the removal of the skylight over the shower and the antenna mount along with some wood rot in front. Up and down an 8' ladder and moving it a few feet at a time for the removal, clean up, and then the installation was no fun. Next time I'm going to use a scaffold or moving lift; it would help in taking the AC unit of the roof. I had those MaxxAir covers over two of my vent and JAG1 still put his hand through the 17 year old plastic vent lids when we went to clean them. I replaced them all and already had, in the trailer, 3 new white MaxxAir covers to put on.
-
What are these wires for!
Have you tried "cock-a-doodle-do" or "Chick-fil-a".
-
Auto Computer Specialist customer service
Thanks for the feed back about this business. It is a shame that customers are put through this. It is hard enough to get professional customer care in face to face transactions; with transactions being done via internet, you're only a number on their screen where there can be a lack of integrity and caring. @pepsi71ocean will see this and update his article "List of Verified and Reliable PCM/ECM Rebuilders" in the 24 Valve 2nd Generation >Engine >Electrical section. You can also visit this article and, in the comment section, link this thread.
-
I want to finish the WT Wiring mod but...
It's looking good. Now just two more thing to do on the wiring under the hood.
-
Posting and Club forms
-
I want to finish the WT Wiring mod but...
You don't need a crimper. I soldered all the cables into the lugs with a small butane torch and rosin core solder. You can use a propane torch on low. I didn't use a breaker. I did a fuse like @JAG1 has on his trucks. It costs a little more than a breaker. https://www.amazon.com/Blue-Sea-Systems-Block-Insulating/dp/B000K2K7TW/ref=sr_1_1?dchild=1&keywords=Blue+Sea+Systems+ANL+Fuse+Block+with+Insulating+Cover+-+35-300A+(5005)&qid=1598808156&s=automotive&sr=1-1-catcorr https://www.amazon.com/NEP-ANL-Fuse-3-Pack-150/dp/B077RF3FWJ/ref=sr_1_3_sspa?dchild=1&keywords=NEP+ANL+fuse+3+pack+(150+amp)&qid=1598808320&s=automotive&sr=1-3-spons&psc=1&spLa=ZW5jcnlwdGVkUXVhbGlmaWVyPUEyVUFVODBGTkFVRjdBJmVuY3J5cHRlZElkPUEyWUFRUFJCOEhZUUFNJmVuY3J5cHRlZEFkSWQ9QTA4MTYyODUxSk1PTVc1OUNDTDQ0JndpZGdldE5hbWU9c3BfYXRmJmFjdGlvbj1jbGlja1JlZGlyZWN0JmRvTm90TG9nQ2xpY2s9dHJ1ZQ==
-
I want to finish the WT Wiring mod but...
Amazon 150 amp circuit breaker https://www.amazon.com/STETION-Circuit-Trolling-12V-48VDC-Waterproof/dp/B07TBF1GVK/ref=sr_1_10?crid=3ICPSG3HB92FB&dchild=1&keywords=circuit+breaker+automotive&qid=1598790776&s=automotive&sprefix=circuit%2Caps%2C193&sr=1-10 The cable is a #6 AGW 1 #6-5/16" lug 1 #6-1/4" lug If you add the above circuit breaker you'll need 2 more #6-1/4" lugs.
-
Alternator Question
Install this then turn on/off grid heaters as needed.
-
Fuel lines torque spec
Hold down 89in-lb High pressure fuel line fittings at injectors 28ft-lb High pressure fuel line fitting at pump 18ft-lb
-
ac quit
Yes, there are two connectors above the fuel filter housing at the firewall. The db/bk wire is in the one with 11 wires in it at pin #4. You need to disconnect the wire harness at C125 then do the ohm testing. This will isolate just the wire in the engine harness and you can see if this is the one shorted to ground. To test the wire from C125 to terminal #87: with C125 still disconnected remove AC relay from PDC, find terminal #87 position and with one probe from the ohm meter touching the terminal and the other touching ground the reading should be L or infinity depending on the meter. Now do the same with the C125 connector still separated at the wire unplugged from the AC compressor and ground. The ohm reading should be the same as above. If in either test the ohm reading is near or at 0 then there is a short in that wire.
-
question about w-t ground mod
Some say yes others say no. For the cost of the cable and the little time it takes to do it, why not do what the man who found the solution did and do it all.
-
Multiple LP failures now hard starting when hot
Disconnect wire in cab from fuse in cab. Remove wire from cab. Attach wire, that you have removed from cab, to the yellow and white wire on the old LP pigtail. You're done; go have a drink.
-
question about w-t ground mod
Nothing, not a thing, goes back where the alternator cable came off the PDC. Think of the power flow like this: old way... power from alternator, through cable, to 140amp fuss in PDC. new way... power from alternator, through cable and 150amp fuse or circuit breaker to right battery, then through cable over top of radiator, to left battery, last to PDC through smaller red cable from left battery.
